4pre — Compact audio interface with four mic preamps and mixing

Extras

Waken your inner engineer with the 4pre’s many advanced extras.

Expansion

Need more inputs and outputs?

Add another 4pre or another MOTU audio interface as your needs grow, by daisy-chaining or by using a standard Firewire or USB 2.0 hub.

The 4pre provides driver-level support for resolving multiple interfaces with each other so that their audio streams never drift apart over time during recording or playback.

Direct SMPTE time code sync

No separate synchronizer required

You can resolve the 4pre directly to SMPTE time code, without a dedicated synchronizer, via any analog input. The 4pre provides a DSP-driven phase-lock engine with sophisticated filtering that provides fast lockup times and sub-frame accuracy. This technology represents the very latest in extremely high-performance, yet cost-effective digital audio clocking. DDS also allows the 4pre to maintain an extremely stable clock while resolved to incoming clock sources that have substantially more jitter than the 4pre itself.

SMPTE Console software

Synchronization made easy

The included SMPTE Console™ software (for Mac OS X and Windows) provides a complete set of tools to generate SMPTE for striping, regenerating or slaving other devices to the computer. Like CueMix, the synchronization features are cross-platform and compatible with all audio sequencer software that supports the ASIO2 sample-accurate sync protocol.




Instrument Tuner

Accurately tune guitars and other instruments

Just open the Tuner window, play a note, and use the large graphic display to get in tune with an accuracy of one 10th of a cent (one 1,000th of a semi-tone). Being in tune has never been easier. The Tuner displays the detected note by frequency (in Hertz), note name and octave, with an adjustable reference frequency for A4 between 400 and 480 Hz. The large meter gives you a clear indication of how high or low you are from the detected pitch. Large red arrows direct you up or down as needed to zero in on the correct pitch. You can even tune phase-coherent stereo signals. The CueMix Tuner is as advanced and accurate as any dedicated hardware tuner out there.




Spectrogram "waterfall"

A cascade of information — in vivid color

Observe rich, detailed visual information about the frequency content of any signal or mix. You can expand the spectrogram to fill the entire resizable CueMix on-screen window. You can also combine the spectrogram with the FFT display in the same display, as shown below, or separate them to view them individually but simultaneously.

FFT display

Visualize your frequency content

Visually monitor the frequency content of your music or other audio material as it plays. The CueMix software superimposes a Fast Fourier Transform directly on the spectrogram display so that you can see the relationship between the two for the audio material being monitored.

X-Y Plot

Check phase alignment with visual clarity

The X-Y Plot window graphs a stereo signal on a standard grid with left-channel amplitude on the x-axis and right-channel amplitude on the y-axis. Stereo material that is said to be "in polarity" (i.e., phase aligned) appears along the x = y axis. Stereo material that has phase problems will appear along the x = -y axis meaning the signal will appear predominantly in the upper left and lower right of the display. A signal with an extremely wide stereo field will appear much more randomly (not along either axis).

Scatter

Linear

Phase Analysis

Check for phase cancellation when summing to mono

In the polar view, the radius represents frequency and the angle (theta) from the +y vertical axis represents the phase difference of left channel minus the right channel. Stereo audio that is generally in phase will appear along the +y axis (above the center point). The more the audio signal "tips" to the left or right, the more out of polarity it is. If it is completely out of phase, it will point downwards from the center point and hover around the -y axis (the part of the y axis below the center point).

The Phase Analysis window graphs frequency versus phase difference versus amplitude of a stereo signal on either rectangular or polar coordinates. In the rectangular view, the vertical axis represents frequency, and the horizontal axis represents the phase of the left channel minus the phase of the right channel. Stereo audio that is predominantly in polarity will appear centered along the center vertical axis. Frequencies that would be canceled by summing to mono are those that touch the -1.0 or +1.0 lines on the left and right.

Scatter

Line

Applications for phase analysis

Phase analysis can be used for a broad range of applications
in the studio and on the stage. Here are just a few ideas.

Recording with multiple mics

The Phase Analysis window lets you compare multiple mic sources with each other to check for potential phase cancellation caused by varying distances in mic placement from the recorded source.

Checking overall polarity

Quickly check the overall polarity in your stereo mix for phase issues.

Summing to mono

If your stereo material needs to be summed to mono, Phase Analysis lets you see what frequencies will be canceled out when summed.

Tuning PAs or sound reinforcement

Place mics in strategic locations in your venue to check for critical phase issues in the listening environment.



Oscilloscope

This is not your grandpa’s oscilloscope…

CueMix’s oscilloscope delivers a robust feature set combined with digital precision. Amplitude is displayed on the y-axis and time is displayed on the x-axis. The pause button lets you “freeze” the real-time display and then zoom in to the sample level for closer examination. You can choose among several different displays for stereo signals, including combined (as shown below) or split screen. The Waveform Recognition feature searches through new audio data looking for matching waveform data, and the trigger options let you specify detailed criteria for displaying the incoming signal’s waveform in the display. The oscilloscope can be used for a variety of daily studio tasks, such as analyzing and comparing harmonic content, closely inspecting transients such as drum hits, comparing timing between two signals, and performing clip detection. You can even use the oscilloscope to help you build synth patches and check them for non-obvious issues, such as DC offset.
